Connection
Traffic from the internet reaches the platform via the connectivity of the data centre in which it runs.
3 locations
Network from data centres in Germany and Finland: our own fibre between three locations and our own routers. Load Balancer, Gateway and addresses are billed per month, traffic in the vRack is not; troubleshooting does not end at a provider boundary.
Prices net plus 19% VAT. 3 locations.
Choose a project, then configure the building blocks — calculated with the same catalogue values and balance as the network configurator. What you put together here, you can add directly to the cart or take into the configurator.
Step 1 · Connection
Two cloud instances behind a layer 7 load balancer, connected via a private network, with two floating addresses for switching during maintenance.
Per instance 20 TB traffic included.
0 to 200
Traffic via your own uplink, unlimited.
0 to 100
Step 2 · Private network
A factor next to the location affects all network items, not the traffic. The milliseconds are the median latency from Frankfurt.
included
Locations in the cluster
Isolated Layer 2 network across all locations. The bandwidth class is charged per participating location; traffic in the vRack is not charged, not even between locations.
Connect requires your own data centre. To do this, tick the box for “Connect own data centre” in step 1.
Step 3 · Public edge
€12.00$13.92net / month
Per instance €12.00$13.92 per month.
1 to 20
Forwarding rules per instance
The first rule is included in the base fee, each additional one costs €0.0060$0.0070 per hour.
included
Standard configuration, included in the price. IPv6 remains free of extra charge in any case.
Migrates to a second system during maintenance; permanently reserved but unused, each costs €1.73$2.01 per month.
bound without charge
Step 4 · Traffic
included
Expected volume per month
40 TB are included, beyond that €1.09$1.26 per TB — the same for every destination and without a location factor.
The discount applies to the monthly net amount. You pay 12 and 24 months in advance with the first invoice.
Seven stations from the outside in; the sections below follow the structure of the network — first our own network, then the transition in, the separation inside, the way out, distribution, protection, delivery and finally the addresses.
Traffic from the internet reaches the platform via the connectivity of the data centre in which it runs.
3 locations
Attack traffic is filtered out before it reaches your systems — without you having to turn anything on.
1.2 Tbit/s, permanently active
Our own fibre connects the locations; if one route fails, the opposite direction takes over.
18.4 Tbit/s · 3 locations
Load Balancer and Floating IP accept connections and distribute them to your systems.
Load Balancer €12.00$13.92 per instance and month
Systems without a public address go out via a shared address and remain unreachable from the outside.
3 size classes
In the vRack, your systems share a segment as if they were connected to the same switch (Layer 2) — even across location boundaries.
vRack 1 Gbit/s included
Cloud instances, dedicated servers and Private Cloud hosts, each system with guaranteed connectivity.
1 × IPv4 + /64 IPv6 per system
Your own data centre as a port on our network edge, instead of a tunnel through the internet.
own data centre, from 10 Gbit/s
Static content goes to visitors from nodes at the network edge, not from your origin.
42 delivery nodes
The locations are connected to a counter-rotating fibre optic ring. If a section fails, the opposite direction takes over — in milliseconds, without a maintenance window.
Locations in the ring
A single section leads to HEL1 in Helsinki: HEL1 is directly next to FRA1 in the ring.

| Option | Surcharge / month |
|---|---|
| 1 Gbit/s guaranteedStandardUnmetered within the included traffic. | included |
| 2 Gbit/s guaranteedDoubled uplink capacity, identical fair use policy. | €100.83$116.96 |
| 3 Gbit/s guaranteedBasic connection of the FORGE series, included in the plan. | €150.41$174.48 |
| 4 Gbit/s guaranteedFor delivering large files from a single location. | €200.83$232.96 |
| 5 Gbit/s guaranteedIntermediate level for streaming and mirror servers. | €250.41$290.48 |
| 10 Gbit/s guaranteedFor storage replication and media delivery. | €500.83$580.96 |
| 25 Gbit/s guaranteedDual-port connection with LACP to redundant switches. | €1,250.41$1,450.48 |
All amounts net, plus 19% VAT.
Every connection is guaranteed, not overbooked. From 10 Gbit/s, it is provided as a dual port with LACP — two ports bundled into one connection — on two separate switches, so a switch restart interrupts nothing.
1 Gbit/s included, up to 25 Gbit/s bookable
Latency — the time a packet takes for the round trip — is the median of a week, measured from Frankfurt am Main against a reference host at the respective location. The capacity specification describes the occupancy of the installed floor space, not the network load. The price factor applies to the net base price of each product, before term discount and VAT apply.
| City | Description | Latency | Occupancy | Price factor | PUE |
|---|---|---|---|---|---|
| Frankfurt am Mainfra1 | Location Rhein-Main | 3 ms | 71% | 1.00 × | 1.14 |
| Düsseldorfdus1 | Location Rhein-Ruhr | 4 ms | 48% | 1.00 × | 1.12 |
| Helsinkihel1 | Location Uusimaa | 21 ms | 36% | 0.94 × | 1.08 |
PUE — the ratio of the total power consumption of a data centre to that of its IT systems — is the annual average of the respective location. The price factor 1.00 designates the reference location Frankfurt am Main; all list prices apply there, net plus 19% VAT.
Connect places your data centre as its own port on our network edge. The traffic then sees two networks, yours and ours — not the twelve in between over which a tunnel through the open internet runs. Behind this lies your vRack with dedicated servers, cloud instances and a Private Cloud on managed hosts.
The port price corresponds to the surcharge for a guaranteed connection of the same speed; a dual cross-connect costs double. The cross-connect in the meet-me room — the room where network operators interconnect their lines — is billed by the building operator, not us.
| Class | Optics | Configuration | Port / month |
|---|---|---|---|
| 10 Gbit/s | 10GBASE-LR, single-mode LC, 1310 nm | Single port. Maintenance on the edge router interrupts the link. | €500.83$580.96 |
| 2 × 10 Gbit/s | 2 × 10GBASE-LR, LACP | Two edge routers in separate fire zones, active/active. | €1,001.66$1,161.93 |
| 25 Gbit/s | 25GBASE-LR, single-mode LC, 1310 nm | Single port. For replication links with maintenance window. | €1,250.41$1,450.48 |
| 2 × 25 Gbit/s | 2 × 25GBASE-LR, LACP | Highest expansion stage, 50 Gbit/s total capacity. | €2,500.82$2,900.95 |
All amounts net, plus 19% VAT. minimum term 12 months, then cancel monthly. We do not offer Connect below 10 Gbit/s — there, an IPsec tunnel carries the same load at a fraction of the cost.

You can reach all other locations via the same port: from the handover point, the traffic continues in our own backbone, not via transit.
3 locations with carrier-neutral meet-me room
A VPN is not a worse version of Connect, but the right answer to a different question. A dedicated port only pays off when latency and throughput must be contractually guaranteed.
We guarantee a 2 ms packet latency as a monthly average to the edge router of the handover location and a packet loss of under 0.01 percent. Measurements are taken every second; the same values in the customer account result in a service credit according to the Service Level Agreement.
Measured between handover port and edge router of the target region
After the order, we provide the port ID and contact in the meet-me room; you order the cross-connect from the building operator. We then activate the port and check the route together with you for optical levels and LACP status.
10 to 20 working days until the light signal
Servers, cloud instances and managed databases are placed in the same broadcast segment — a network section where a broadcast message reaches every system — even if they are located in Frankfurt am Main, Düsseldorf and Helsinki. The traffic never leaves the ENTRONYX CLOUD network. The same segment is shared by dedicated servers and the cloud instances on which Managed Kubernetes runs its worker nodes.
| Option | Price / month |
|---|---|
| No private network | included |
| vRack 1 Gbit/sStandardIsolated Layer 2 network across all locations. | included |
| vRack 10 Gbit/sFor storage replication and database clusters. | €39.00$45.24 |
| vRack 25 Gbit/sDedicated fabric for HPC and hypervisor clusters. | €119.00$138.04 |
| vRack 50 Gbit/sFor distributed storage pools whose write path runs over the private network. | €219.83$255.00 |
| vRack 100 Gbit/sHighest expansion stage for clusters with synchronous replication between fire zones. | €421.49$488.93 |
All amounts net, plus 19% VAT.
Cluster software often expects a shared segment: Keepalived with VRRP, Proxmox-Corosync, database failover with a floating virtual IP. On a routed network, this is only possible with workarounds.
Technically, the vRack is a VXLAN overlay with EVPN: VXLAN encapsulates your Layer-2 frames into packets for our routed network, EVPN distributes which address is at which location. In the system, you see a second network adapter, unconfigured and without DHCP.
VXLAN with EVPN control plane
For storage replication and backups, a larger MTU — the maximum packet length a segment carries — brings measurable throughput because there are fewer packets and interrupts. Prerequisite: every system in the segment uses the same MTU.
A single host with 1500 bytes otherwise causes fragmentation and hard-to-find timeouts; therefore, you set the MTU per VLAN, not per system.
9000 byte MTU reduces overhead by about 4 percent
Instances in a private segment need to fetch packages, renew certificates and send telemetry without being accessible from the internet themselves. The gateway translates their outgoing connections to a shared public address and lets nothing in from the outside.
The class determines the throughput and the number of concurrent translations — one translation corresponds to one connection. Switching between classes happens without interruption because the state is transferred to the new pair.
| Class | Throughput | Concurrent translations | New per second | Price / month |
|---|---|---|---|---|
| Gateway S | 1 Gbit/s | 500,000 | 40,000 | €12.00$13.92 |
| Gateway M | 2 Gbit/s | 1,000,000 | 80,000 | €112.83$130.88 |
| Gateway L | 10 Gbit/s | 2,000,000 | 200,000 | €512.83$594.88 |
All amounts net, plus 19% VAT. The amount consists of the base fee for a managed network instance and the surcharge for the respective throughput class — the same as an uplink of the same speed costs. Outbound traffic via the gateway is not charged separately.
There is no port forwarding and no inbound rule: a connection from the outside finds no way back because there is no entry for it in the translation table. If you need to be reachable inbound, use a Load Balancer or a public address on the system.
No forwarding from outside to inside
Every gateway runs as a pair, and the translation table is continuously synchronised: existing connections pause briefly during a failover instead of dropping. Maintenance uses the same failover mechanism, so no maintenance window is required.
Active/passive across two fire zones · failover under 3 s
All systems behind the same gateway show the same source address, which you can provide to partners and add to access lists. It is permanently assigned and does not change during a failover or when changing the size class.
One source address for access lists
A load balancer can simultaneously pass through TCP ports and distribute HTTP requests by path. Both run on redundant hardware in at least two fire compartments.
Distributes TCP and UDP connections without looking into the content. The connection remains end-to-end encrypted, the load balancer only sees addresses and ports.
Terminates TLS, reads host and path and distributes accordingly. Headers can be set, removed and rewritten; redirects and rate limiting are part of the rule.
Checks are performed via TCP connection establishment or HTTP request against a freely selectable path with an expected status range and custom host header. When removed, existing connections drain — 30 seconds by default, adjustable up to one hour.
Interval 2 to 60 s · standard 5 s
You upload certificates or obtain and renew them automatically via ACME, the protocol used by certificate authorities to issue certificates automatically. Per hostname, RSA-2048 and ECDSA P-256 go out in parallel; on layer 7, the instance also verifies client certificates (mTLS) against a custom CA upon request.
TLS 1.2 and 1.3 · up to 100 certificates per instance
A load balancer instance costs €12.00$13.92 per month — with the first forwarding rule, unlimited traffic and TLS termination. Each additional rule is billed by the hour at €0.0060$0.0070 per hour, which is €4.38$5.08 in an average month with 730 hours.
1 rule (included)
€12.00$13.92
per month
Base fee €12.00$13.92, no additional rule
11 rules
€55.80$64.73
per month
Base fee €12.00$13.92 + rules €43.80$50.81
51 rules
€231.00$267.96
per month
Base fee €12.00$13.92 + rules €219.00$254.04
Per instance, all amounts net, plus 19% VAT. · billed by the hour


Filter capacity 1.2 Tbit/s — as much traffic as 48 systems with the largest bookable connection (25 Gbit/s) could generate together. At ENTRONYX CLOUD, the filtering runs permanently; it is not switched on.
Basic protection is included in every product and does not need to be switched on. It runs permanently, not just after a call to support.
1.2 Tbit/s
As much traffic as 48 systems with 25 Gbit/s could generate combined.
Amplification attacks via DNS, NTP, memcached and SSDP, SYN and ACK floods, fragmented packets, attacks with spoofed source addresses. This class accounts for the vast majority of incidents.
Volumetric, Layer 3 and 4
Request floods against expensive endpoints, Slowloris — attacks that intentionally keep connections open —, distributed login attempts and attacks that behave like real users. These patterns cannot be cleanly separated volumetrically.
Layer 7 · from €49.00$56.84 per month, net
| Option | Price / month |
|---|---|
| Basic DDoS protectionStandardVolumetric filtering up to 1.2 Tbit/s. Included in every plan. | included |
| DDoS protection advancedLayer 7 analysis, behaviour patterns and individual mitigation rules. | €49.00$56.84 |
| DDoS protection gamingProtocol-specific filters for UDP game protocols with under 1 ms additional latency. | €89.00$103.24 |
All amounts net, plus 19% VAT.
A PoP is a delivery location at the network edge; Anycast means that all are reachable under the same IP address and every device ends up at the nearest one. Routing there is handled by the network, not a DNS trick waiting for expiring caches.
Rules apply to path patterns, file extensions, methods, headers and query parameters, and determine cache duration, vary headers and the passing of cookies. Without a rule, the cache control of the origin applies; if that is also missing, nothing is cached.
Up to 100 rules per zone, evaluated from top to bottom
Invalidation can be done individually by URL, by prefix or via cache tags that the origin includes in the response header. For deployments, tags are preferable: one call instead of a thousand URLs.
At all PoPs under 30 s · 5,000 requests per day
All PoPs fetch missing objects via an upstream intermediate layer; this typically reduces requests to the origin by 90 percent when the cache is cold. If the origin fails, the CDN continues to deliver the last valid response for up to 24 hours (Stale-While-Revalidate).
Origin Shield at a location of your choice
Billing is based on the volume that the PoPs deliver to end devices; fetching from the origin, TLS, HTTP/3 and invalidation are included. The tiering is sliding: each terabyte costs the rate of the tier it falls into.
First 10 TB
€9.90$11.48
per TB
Entry tier, no minimum commitment
10 to 100 TB
€7.40$8.58
per TB
Automatically upon exceeding the first tier
100 to 500 TB
€5.20$6.03
per TB
Typical tier for media libraries
From 500 TB
€3.90$4.52
per TB
Above this on request with annual commitment
Example: 50 TB per month cost 10 × €9.90$11.48 + 40 × €7.40$8.58 calculated on a sliding scale = €395.00$458.20, net plus 19% VAT.
Every system comes with one IPv4 address and a /64 IPv6 prefix; we allocate further IPv4 subnets according to the rules of the RIPE NCC, the address registry for Europe. Below: the address that moves between systems.
| Option | Price / month |
|---|---|
| 1 × IPv4 + /64 IPv6StandardStandard configuration, included in the price. | included |
| /30 subnet (4 × IPv4)2 additional usable addresses. | €6.00$6.96 |
| /29 subnet (8 × IPv4)6 additional usable addresses. | €14.00$16.24 |
| /28 subnet (16 × IPv4)14 additional usable addresses. | €27.00$31.32 |
| /27 subnet (32 × IPv4)Proof of use required30 usable addresses. Justification required according to RIPE policy. | €52.00$60.32 |
All amounts net, plus 19% VAT. · no setup fee
IPv4 addresses have been exhausted since 2019, the RIPE NCC only allocates from returned pools. From a /27 upwards, we therefore require evidence of use; the review usually takes one working day.
We reclaim unused allocations after 60 days.
Evidence required from a /27
A /64 is enough for one segment, a /48 for an entire network with 65,536 segments; both cost nothing. You set reverse DNS records — the name an address returns in a reverse lookup — yourself in the customer account.
/64 included, /48 on request
A floating IP belongs to the account, not the system: you switch it from one instance to another within a location — during failover, version upgrades or when replacing a server. The detour via DNS is eliminated, and with it the waiting time until a TTL — the validity period of a DNS record — has expired in every cache.
As long as the address is attached to a running system, it costs nothing extra. You are only charged for reservation without usage — the case where a scarce address is occupied without working.
Bound to a system
without charge
Counts as the included IPv4 address of this system.
Reserved, not bound
€0.0024$0.0028 / h
€1.73$2.01 per month
The address remains allocated to you and is not available to anyone else.
60 days unassigned
not applicable
The allocation will be revoked after notification — the same rule as for unused subnets.
All amounts net, plus 19% VAT. The hourly rate is derived from the IPv4 scale: €52.00$60.32 for a /27 with 30 usable addresses results in €1.73$2.01 per address and month, divided by 730 hours. Calculations are unrounded, rounding only occurs on output.
8 frequently asked questions. The answers use the same catalogue values as the sections above.
Can't find your question? Describe your project to us.
A guaranteed connection with 1 Gbit/s, an IPv4 address including a /64 IPv6 prefix and basic DDoS protection with 1.2 Tbit/s filtering capacity. In addition, the vRack 1 Gbit/s acts as a private network between your systems; traffic within it is not charged.
From 10 Gbit/s continuous load or as soon as term and throughput must be contractually guaranteed. Below that, an IPsec tunnel over the internet carries the same load at a fraction of the cost.
Port 10 Gbit/s per month, net€500.83$580.96
The gateway shares a public address among many systems, outbound only, and no one from the outside can reach the systems behind it. A Floating IP belongs to exactly one system, works in both directions and can be switched to another system for failover.
Bound to a running system, nothing, because it counts as its included IPv4 address. Only the reservation without a binding is charged, by the hour; after 60 days without a binding, the address is reclaimed.
Reserved without binding, per month net€1.73$2.01
The border routers detect it in a continuous sample of the traffic and redirect the attacked address to the filtering centres in Frankfurt am Main, Düsseldorf and Helsinki; after 18 seconds they filter. The redirection ends 15 minutes after the attack, after which a report is available in the customer account — without you having to open a ticket.
The network runs at three locations in Germany and Finland and connects them via a dedicated fibre optic ring with 18.4 Tbit/s capacity. Every location is within the scope of the GDPR; traffic in the vRack does not leave the ENTRONYX CLOUD network.
Via ticket in the account: The price includes the basic support of the SLA with an initial response in 8 hours for critical incidents (P1), available Monday to Friday from 08:00 to 18:00. Initial response means: A human has accepted the report, classified it and reported back the processing status — the SLA does not guarantee a resolution time. In addition to basic support, it offers three further support levels; the highest responds to P1 in 15 minutes.
Not without a term commitment: You can delete services billed by the hour at any time without notice in the console or via the API, and billing ends at the time of deletion (Section 11 paragraph 3 of the Terms and Conditions). You can cancel monthly contracts with one day's notice to the end of the term, contracts for 12 or 24 months with 30 calendar days — otherwise they renew for twelve months (Section 11 paragraph 2 of the Terms and Conditions). You pay the term in advance and receive a 5% or 8% term discount in return.
In the network planner above, you can add your selection directly to the cart or take it into the network configurator. Connect is handled via the enquiry, because it requires a cross-connect. The amounts are the same as in the checkout process.
